Solid Of Revolution Volume: A Step-by-Step Calculation

by ADMIN 55 views

Hey everyone! Today, we're diving into a super interesting problem: figuring out the volume of a solid of revolution. Specifically, we'll be looking at the region bounded by the curves y = 1 + sec(x) and y = 3, rotated around the line y = 1. Sounds like a mouthful, right? But don't worry, we'll break it down step by step. This is a classic calculus problem that combines integration with a bit of spatial reasoning, so let's get started!

Understanding the Problem

Before we jump into the math, let's make sure we understand what we're trying to do. Solids of revolution are 3D shapes formed by rotating a 2D region around a line. Think of it like putting clay on a pottery wheel – as the wheel spins, the clay takes on a three-dimensional form. In our case, the region we're rotating is bounded by two curves: y = 1 + sec(x) and y = 3. The axis of rotation is the horizontal line y = 1. So, imagine this 2D region spinning around y = 1; it'll create a solid shape, and our goal is to find the volume of that shape.

Visualizing the Region

To really grasp what's going on, let's visualize the region. The curve y = 1 + sec(x) might look a bit intimidating, but it's essentially a shifted secant function. Remember that sec(x) = 1/cos(x), so it has vertical asymptotes where cos(x) = 0, which are at x = ±π/2, ±3π/2, and so on. The +1 just shifts the entire graph up by one unit. The line y = 3 is a simple horizontal line. We're interested in the region where 1 + sec(x) is less than or equal to 3. Sketching these curves will give you a clear picture of the area we're dealing with. This visual representation is crucial because it helps us understand the limits of integration and the overall shape of the solid.

Choosing the Right Method: Disk or Washer?

Now that we have a visual, we need to decide how to calculate the volume. There are two main methods for finding volumes of revolution: the disk method and the washer method. The disk method is used when the region is flush against the axis of rotation, meaning there's no gap between the region and the axis. The washer method, on the other hand, is used when there's a gap, creating a “washer” shape when the region is rotated. In our case, there's a gap between the curve y = 1 + sec(x) and the axis of rotation y = 1, so we'll be using the washer method. The washer method involves integrating the difference between the areas of two circles: an outer circle and an inner circle. The outer circle's radius is the distance from the axis of rotation to the outer curve, and the inner circle's radius is the distance from the axis of rotation to the inner curve. Understanding when to use each method is a key step in solving these types of problems.

Setting Up the Integral

Alright, let's get to the fun part: setting up the integral. The formula for the washer method when rotating around a horizontal line is:

V = π ∫[a, b] (R(x)² - r(x)²) dx

Where:

  • V is the volume.
  • π is, well, pi.
  • [a, b] are the limits of integration (the x-values where the region starts and ends).
  • R(x) is the outer radius (the distance from the axis of rotation to the outer curve).
  • r(x) is the inner radius (the distance from the axis of rotation to the inner curve).

Finding the Radii

First, we need to determine our radii. Remember, we're rotating around the line y = 1. The outer curve is y = 3, so the outer radius R(x) is the distance between y = 3 and y = 1, which is simply 3 - 1 = 2. The inner curve is y = 1 + sec(x), so the inner radius r(x) is the distance between y = 1 + sec(x) and y = 1, which is (1 + sec(x)) - 1 = sec(x). So, we have R(x) = 2 and r(x) = sec(x). Identifying the outer and inner radii correctly is crucial for setting up the integral properly. A small mistake here can throw off the entire calculation.

Determining the Limits of Integration

Next up, we need to find the limits of integration, a and b. These are the x-values where the curves y = 1 + sec(x) and y = 3 intersect. To find these points, we set the two equations equal to each other:

1 + sec(x) = 3

sec(x) = 2

Since sec(x) = 1/cos(x), this is equivalent to:

1/cos(x) = 2

cos(x) = 1/2

The solutions to this equation in the interval where our region is defined (typically around the y-axis) are x = π/3 and x = -π/3. These are our limits of integration: a = -π/3 and b = π/3. The limits of integration define the interval over which we're summing up the infinitesimally thin washers to find the total volume. Accurate limits are essential for a correct volume calculation.

Plugging It All In

Now we have everything we need to set up the integral:

V = π ∫[-π/3, π/3] (2² - sec²(x)) dx

V = π ∫[-π/3, π/3] (4 - sec²(x)) dx

Evaluating the Integral

Okay, we've set up the integral, now it's time to evaluate it. This involves finding the antiderivative of the integrand and then applying the limits of integration.

Finding the Antiderivative

The integrand is 4 - sec²(x). We can split this into two parts: the integral of 4 and the integral of sec²(x). The integral of 4 with respect to x is simply 4x. The integral of sec²(x) is a standard integral that you might want to memorize (or look up in a table of integrals): it's tan(x). So, the antiderivative of 4 - sec²(x) is 4x - tan(x). Knowing common antiderivatives is a huge time-saver in calculus. If you're not familiar with them, it's worth spending some time memorizing or creating a reference sheet.

Applying the Limits of Integration

Now we need to evaluate the antiderivative at the upper and lower limits of integration and subtract the results. This is the Fundamental Theorem of Calculus in action! So, we have:

V = π [(4(π/3) - tan(π/3)) - (4(-π/3) - tan(-π/3))]

Let's simplify this. We know that tan(π/3) = √3 and tan(-π/3) = -√3. So, we get:

V = π [(4π/3 - √3) - (-4π/3 + √3)]

V = π [4π/3 - √3 + 4π/3 - √3]

V = π [8π/3 - 2√3]

The Final Answer

Finally, we have our volume:

V = π(8π/3 - 2√3) cubic units

This is the exact volume of the solid of revolution. We can also get a decimal approximation by plugging this into a calculator, but the exact answer is often preferred in calculus problems. This final answer represents the three-dimensional space enclosed by the solid we created by rotating the region between the curves. It's a tangible result of all the calculus we've done!

Key Takeaways and Tips

Wow, we made it! We successfully calculated the volume of a solid of revolution. That's a big accomplishment! Let's recap some key takeaways and tips for tackling these types of problems:

  • Visualize, visualize, visualize: Always start by sketching the region and imagining the solid. This will help you understand the problem and choose the right method.
  • Choose the right method: Decide whether to use the disk or washer method based on whether there's a gap between the region and the axis of rotation.
  • Identify the radii: Carefully determine the outer and inner radii for the washer method, or the radius for the disk method.
  • Find the limits of integration: Determine the points of intersection of the curves to find the limits of integration.
  • Set up the integral correctly: Plug the radii and limits into the appropriate formula.
  • Evaluate the integral: Find the antiderivative and apply the Fundamental Theorem of Calculus.
  • Simplify your answer: Simplify the expression as much as possible and include units in your final answer.

Practice Makes Perfect

The best way to master these concepts is to practice! Try working through similar problems with different curves and axes of rotation. You can also explore online resources and textbooks for more examples and explanations. The more you practice, the more comfortable you'll become with setting up and evaluating these integrals. Each problem you solve will build your problem-solving skills and deepen your understanding of calculus.

Common Mistakes to Avoid

It's also helpful to be aware of common mistakes that students make when solving these problems. Here are a few to watch out for:

  • Incorrect radii: Mixing up the outer and inner radii is a common error. Always double-check which curve is farther from the axis of rotation.
  • Wrong limits of integration: Make sure you're finding the correct intersection points and using the appropriate x-values (or y-values if you're integrating with respect to y).
  • Forgetting the π: The π is an important part of the volume formula, so don't forget to include it!
  • Integration errors: Make sure you're finding the correct antiderivatives and applying the Fundamental Theorem of Calculus correctly.
  • Units: Always include units in your final answer (e.g., cubic units). Remembering these common pitfalls can help you avoid making simple mistakes and ensure you arrive at the correct solution.

Conclusion

Calculating the volume of a solid of revolution can seem daunting at first, but by breaking it down into steps and understanding the underlying concepts, you can conquer these problems. Remember to visualize the problem, choose the right method, set up the integral carefully, and evaluate it accurately. With practice, you'll become a pro at finding volumes of solids of revolution! Keep up the great work, and happy calculating, guys!
