Jackson's Current Loop Field Error: A Detailed Derivation

Hey there, physics enthusiasts! Ever found yourself wrestling with the intricacies of electromagnetism, particularly when diving into the depths of Jackson's Classical Electrodynamics? If so, you're definitely in the right place! Today, we're going to dissect a particularly juicy bit from the book – the derivation of the magnetic field due to a current loop, focusing on a specific integral that often leaves students scratching their heads. Buckle up, because we're about to embark on a journey through the fascinating world of vector potentials, elliptical integrals, and approximations!

The Infamous Integral: A Deep Dive

Okay, let's cut to the chase. The heart of our discussion lies in a specific integral that pops up on page 182 of the 3rd edition of Jackson's Classical Electrodynamics. To keep things concise, we'll represent the integral in its simplified form:

I = ∫[0 to 2π] (cos(φ') dφ') / √(a² + r² - 2ar cos(φ'))

This integral, my friends, is no walk in the park. It arises when we're trying to calculate the magnetic field generated by a current loop at a point in space. The variables here are quite important:

• a: represents the radius of the current loop.
• r: signifies the distance from the center of the loop to the point where we're calculating the field.
• φ': is the azimuthal angle, which parameterizes the position along the loop.

So, where does this integral come from, and why is it so crucial? To understand that, we need to rewind a bit and look at the bigger picture of how we calculate magnetic fields.

From Vector Potential to the Integral

The journey begins with the vector potential, often denoted by A. The vector potential is a powerful tool in electromagnetism because it simplifies the calculation of the magnetic field B. Instead of directly calculating B using the Biot-Savart law (which can be quite cumbersome), we can first find A and then take its curl to obtain B (B = ∇ × A). For a current loop, the vector potential at a point in space is given by an integral involving the current density and the distance from the source point to the field point. When we specialize this general expression for a circular loop of radius a carrying a steady current I, and we choose to calculate the field at a point in the plane of the loop (for simplicity), we inevitably stumble upon the integral I mentioned above. The denominator, √(a² + r² - 2ar cos(φ')), represents the distance between a point on the loop (defined by φ') and the point where we're calculating the field. The numerator, cos(φ'), arises from the specific geometry of the problem and the component of the current that contributes to the vector potential in the direction we're interested in.

Now, here's the catch: this integral isn't one you can solve with a simple trick or a quick substitution. It belongs to a class of integrals known as elliptic integrals. Elliptic integrals are notorious for not having closed-form solutions in terms of elementary functions (like sines, cosines, exponentials, etc.). This means we can't write down a neat, compact formula for the result. Instead, we often have to resort to approximations or numerical methods.

Tackling the Beast: Approximations and Expansions

So, how does Jackson (and other physicists) deal with this pesky integral? The key is to employ approximations. We can't get an exact answer, but we can get very close by considering specific cases where the integral simplifies. A common approach is to use a binomial expansion. This involves rewriting the denominator in a form that allows us to use the binomial theorem:

√(a² + r² - 2ar cos(φ')) = √((a + r)² - 4ar cos²(φ'/2))

Now, we can factor out either a or r from under the square root, depending on which limit we're interested in:

1. Case 1: r << a (Field point inside the loop):

   If we're interested in the magnetic field at a point inside the loop (i.e., the distance r from the center is much smaller than the radius a), we factor out a:

   √(a² + r² - 2ar cos(φ')) ≈ a √(1 + (r/a)² - 2(r/a) cos(φ'))


   We can then use the binomial expansion (1 + x)^n ≈ 1 + nx for small x. In this case, x = (r/a)² - 2(r/a) cos(φ'), and since r << a, x is indeed small. This allows us to approximate the square root and simplify the integral.

2. Case 2: r >> a (Field point far from the loop):

   Conversely, if we're interested in the field at a point far from the loop (i.e., r is much larger than a), we factor out r:

   √(a² + r² - 2ar cos(φ')) ≈ r √(1 + (a/r)² - 2(a/r) cos(φ'))


   Again, we can apply the binomial expansion, this time with x = (a/r)² - 2(a/r) cos(φ'). Since a << r, x is small, and we can approximate the square root. This approximation is particularly useful for understanding the far-field behavior of the magnetic field, which resembles that of a magnetic dipole.

The Elliptic Integral Connection

While the binomial expansion gives us a handle on the integral in limiting cases, it's important to acknowledge the connection to elliptic integrals. The integral I can be expressed exactly in terms of complete elliptic integrals of the first and second kind, denoted by K(k) and E(k), respectively. These are special functions that are well-studied and can be evaluated numerically. The modulus k of the elliptic integrals is related to the geometry of the problem:

k² = 4ar / (a + r)²

So, while we might not get a simple closed-form solution, we can express the result in terms of these well-defined special functions. This is often a crucial step in obtaining accurate numerical results or for further analytical manipulations.

Why This Matters: The Significance of the Current Loop Field
